I built three small text generators last month. They share every line of architecture code, yet they do completely unrelated things. That was the point.
Key Takeaways
- Three projects, one decoder-only sequence engine (6 layers, 6 heads, 384 dimensions), trained from scratch in PyTorch
- ASCII Cartographer generates roguelike maps, Feline Monologue answers as a judgmental cat, Hardware Whisperer rewrites English as pseudo-8086 assembly
- The shared architecture proved that tokenizer, training data, and validators matter more than scale
Why three instead of one
The original idea was a single demo. But one system doesn’t prove the architecture is reusable. Three wildly different outputs from the same training skeleton do.
Each project uses a small decoder-only sequence architecture: 6 layers, 6 attention heads, 384-dimensional embeddings. Saved state files with the tokenizer baked into the .pt file. Resumable fp16 training via GradScaler. All three run on inexpensive cloud GPUs.
ASCII Cartographer
This one takes a text prompt like “dungeon with water tiles and three rooms” and emits a fixed 24x12 ASCII roguelike map. Correct walls, doors, water glyphs, and a legend at the bottom.
The training data came from five procedural map generators: BSP rooms, cellular-automata caves, drunkard’s-walk tunnels, overworld terrain, and composite scenes. Each generator writes ground-truth descriptions of what it placed, so the training pairs are self-describing.
I used a char-level tokenizer instead of BPE. BPE eats whitespace unpredictably, which breaks column arithmetic in grids. Structural validators catch bad outputs: dimension checks, glyph whitelists, legend consistency, and flood-fill connectivity to ensure no floating rooms.
Feline Monologue Engine
Every question gets answered as a dramatic, deeply judgmental house cat. The persona bible defines twenty recurring motifs (the food bowl, the void, the red dot), twenty-one forbidden assistant-speak phrases, and six gold example responses.
Training data came through a message-batch API, with a seeded offline mock for local iteration. Byte-level BPE tokenizer at 8k vocab. The interactive interface includes a disdain slider that maps directly to temperature. Crank it up and the cat gets progressively more unhinged.
Hardware Whisperer
English goes in. Pseudo-8086 assembly comes out. A rule-based rewriter maps verbs to opcodes (go becomes JMP, check becomes CMP, stop becomes HLT) and assigns nouns to registers. An 8086 opcode and register whitelist validator rejects anything that doesn’t look like plausible assembly.
The interface is CRT-styled: green-on-black monospace with a scanline effect. Looks impressive in a screenshot, but the system is doing something different from the rule-based rewriter underneath.
What I learned
The shared architecture was the real point. A 384-dimensional decoder-only engine is a blank canvas. It doesn’t care whether it’s generating maps, monologues, or machine code. The tokenizer, the training data, and the post-processing validators do the heavy lifting. The system is just the pattern-matching engine underneath.
All three are MIT licensed, with Pytest suites, interactive demos, and shared notebooks. Links are in each project’s repo.
